Custom glass loading machine
2.Air floating system
3.Max glass size:3660*2440mm
4.Can be customized
5.360 degree walking
- Product Description
Custom Glass Loading Machine - Revolutionizing Glass Handling Efficiency
Huashil Machine is a leading manufacturer and supplier of products, offering innovative solutions for the glass industry. Our state-of-the-art custom glass loading machine combine precision engineering with advanced automation to streamline glass handling processes and boost productivity.
Technical parameters :
| Machine parameters | Table size | 3600mm*2400mm*870mm |
Loading Depth | 750mm | ||
Power Requirements | 3P/380V/50HZ | ||
Air source requirements | Compressed air0.6~0.8MPa | ||
Installed power | about7.5kW | ||
Processing parameters | loading size | Max.3660*2440mm | |
glass thickness | 3~19mm | ||
loading time | 1~2min | ||
|
|
Main configurat
Product Configuration | Mechanical part | Air flotation fan | High pressure centrifugal fan 926-3kW |
Vacuum Pump | Rotary vane centrifugal pump XD-030 | ||
Flip reducer | reducer RV110-1/80-2.2kW | ||
Telescopic reducer | reducer RV63-1/20-0.75kW | ||
Travel reducer | RV reducer RV63-1/20-0.75kW | ||
Flip sprocket | 16A double row sprocket chain | ||
Boom Cylinder | SD100*125 | ||
Ejector Cylinder | SD63*50 | ||
Anchor cylinder | SD75*75adjustable | ||
Vacuum suction cup | 150 double-layer suction cup, made of nitrile rubber | ||
|
| ||
Electrical Parts | Control board | Mitsubishi board | |
Frequency Converter | Inovance 1.5kW | ||
Remote Control | Taylor F21-E1B | ||
Solenoid valve | AirTac | ||
Proximity switches | Omron | ||
Contactor | Delixi |
Why Choose Us?
✅ 10+ Years Expertise – Trusted by glass processors in the USA, Europe & Asia.
✅ Smart Factory Ready – Real-time monitoring & automated loading for higher efficiency.
✅ End-to-End Customization – Tailored sizes, colors, and automation features.
✅ Reliable After-Sales – 24/7 technical support & spare parts availability.
Key Features & Benefits
🔹 3-Arm Automatic Loading – Minimizes manual handling for faster production.
🔹 Air Floating System – Zero-contact transport prevents scratches (2.2KW fan).
🔹 360° Walking Flexibility – Adapts to tight factory layouts.
🔹 Max Load Size: 3660×2440mm – Handles large architectural & automotive glass.
🔹 Multi-Industry Use – Ideal for solar, insulating, and decorative glass.
Product Parameters:
| Feature | Specification |
|---|---|
| Loading Size | 3660*2440mm |
| Glass Thickness Range | 2 mm - 19 mm |
| Power Requirement | 380V, 50Hz |
| Control System | PLC with user-friendly interface |
| Loading Speed | Adjustable, up to 50 sheets/hour |
| Dimensions (L x W x H) | Customizable to fit production line |
| Safety Features | Automatic stop, overload protection |
Product Details:
Our product features a robust frame and precision-engineered components. The three grand arms provide stable and secure glass handling, while the air floating system ensures smooth movement without scratching. The 360-degree walking capability allows for flexible positioning in your production line.
Quality Control:
We implement strict quality control measures throughout the manufacturing process. Each custom glass loading machine undergoes rigorous testing and comes with a mechanical test report. We also offer video factory inspections for added assurance.
Customization Options:
Tailor your product to your specific needs. We offer customization in glass size capacity, color, and integration with existing systems. Our team works closely with you to design the perfect solution for your production requirements.
Certification:
Our products are ISO9001 and CE certified, ensuring compliance with international quality and safety standards.
After-Sales Service:
Huashil Machine provides comprehensive after-sales support, including installation guidance, operator training, and prompt technical assistance. Our global service network ensures quick response times and minimal downtime.
Packaging:
We use sturdy, export-grade packaging to ensure your product arrives in perfect condition. Special care is taken to protect sensitive components during transit.
Company Introduction:
Huashil Machine is at the forefront of glass processing technology, specializing in products and other innovative solutions. Our commitment to quality and customer satisfaction has made us a trusted partner in the global glass industry.
For more information about our custom glass loading machine or to discuss your specific requirements, please contact us at salescathy@sdhuashil.com. Experience the future of glass handling with Huashil Machine's custom glass loading solutions.
